Custom 304 Stainless Steel Worm Gear Hose Clamp
INQUIRY
Description
Our 304 Stainless Steel Hose Clamps are precision-engineered fasteners designed for reliable pipe and hose connections across a wide range of applications. Whether you need a universal worm gear clamp for general plumbing, a constant tension spring clamp for automotive cooling systems, or a heavy-duty clamp for industrial hydraulics, we offer solutions that combine durability, corrosion resistance, and ease of installation.
Parameter
| Parameter | Details |
|---|---|
| Product Name | 304 Stainless Steel Hose Clamp / Pipe Clamp |
| Material | 304 Stainless Steel (A2) – Band, Housing, Screw |
| Standards | SAE J1508, DIN 3017, ASME B18.2.1 (screw) |
| Band Width | 9mm (3/8″), 12mm (1/2″), 14mm (9/16″), 20mm (3/4″) |
| Band Thickness | 0.6mm – 0.8mm (standard); 0.8mm – 1.0mm (heavy duty) |
| Clamping Diameter Range | 6mm – 150mm (1/4″ – 6″) standard; up to 300mm (12″) heavy duty |
| Screw Head | Slotted hex (5/16″ or 7mm) – combination drive available |
| Torque Capacity | 20-40 in-lbs (2.3-4.5 Nm) standard; up to 80 in-lbs heavy duty |
| Temperature Range | -40°C to +150°C (-40°F to +300°F) |
| Surface Finish | As-machined |
